Fuzz Face

This is the Fuzz Face, the legendary fuzz distortion pedal. With this PCB you can build the original or many other variants using either Germanium or Silicon transistors.
Steps
  1. Overview
  2. Designators and components
  3. PCB assembly
  4. Enclosure and wiring
  5. Enclosure drilling
Categories
Tayda Electronics Kits, DIY Projects, DIY Guitar Effects
Created by DHEA
Status: Active
6ad5cfedb16d6a272994ad5c2b2b82c7?s=30

Fuzz Face Step 1 of 5

Dhb2_3

This is the Fuzz Face, the legendary fuzz distortion pedal. With this PCB you can build the original or many other variants using either PNP or NPN transistors. You can use a trimmer to easily adjust the bias point and behavior of the circuit.
